Nylite shackle assembly

Samson Nylite Spool, Shield, Shackle

Samson
SKU:
SM964-SHK

For availability and pricing call 509-291-3024 or email cbknot@cbknot.com

(No reviews yet)
Weight:
3.00 LBS
Width:
8.00 (in)
Height:
8.00 (in)
Depth:
10.00 (in)
Current Stock:
Description

NYLITE ASSEMBLIES

NYLITE CONNECTOR ASSEMBLY PRODUCT CODE: 964

Spool, shield, and shackle
Easily installed into or removed from a premade soft eye. Nylite spool is only 1/7th the weight of steel. Connectors will not deform or rupture from repeated loadings. The shackle takes advantage of the high-strength Nylite connector and synthetic rope.

Working Details

  • Working loads, as given, are based on pin-bore relationships provided by use of the Nylite Shackle. When using a non-standard pin, the workding load as given DOES NOT APPLY.
  • The HP aluminum spool is available for use with high-performance Class II ropes in sizes -1 through -5.
  • Aluminum spools are not recommended for continuous use in submerged marine environments.
  • All working load values are based on a 4:1 safety factor.
  • Assembly ratings are based on the use of designated spools and shackles. Spools used in conjunction with other hardware are not rated by Samson.
